RG174 vs RG316 compare

COMPARISON THE TECHNICAL DATA – COAXIAL CABLE RG174 vs RG316

Here you can see at first sight the characteristics of each coaxial cable, possibly from different manufacturers.

Cable A Cable B

Electric Unit
Description RG174 A/U Koaxialkabel RG316 /U Koaxialkabel
Cable Article Number [Order No.] 050239 050243
Information page [Link] Link Link
Preise [€] 0,35 to 0,41 € 1,86 to 2,19 €
Manufacturer unbranded unbranded
Addition D= 2,80 mm / PVC / Temp: -30°C bis +70 °C D= 2,54 mm / FEP / Temp: -100°C bis +200°C
Impedance [Ω] 50 50
Capacity [pF/m] 100 95
Sheath material [mm/Ø] 2.8 2.54
[Material] PVC FEP
[Colour] black black
Inner conductor [mm/Ø] 0.5 0.9
[Material] Steel copper
strand
Copper stranded
wire
silver-plated
Frequency [max/GHz] 1 1
Max. Voltage [V]
Cable attenuation [db/400MHz] 0.55 0.53
[db/1GHz] 0.88 0.93
[db/2GHz]
Shield 1 Kupfergeflecht verzinnt Kupfergeflecht versilbert
2
3
Shield 1 PE PTFE
2
Shielding factor [db] 52
Velocity [%/c] 66 69
Delay [ns/m]
Mechanical
Temperature max. [°C] +70 +200
min. [°C] -30 -100
Bending radius single [mm] 14 13
repeated [mm] 28 25
Weight [kg/m] 0.012 0.015
Halogen-free
Trailing cable
No Magnetic
Information
Data sheet Datasheet (130 KB) Datasheet (267 KB)
Further information Link Link

Legend:
Compare selection cable A with selection cable B

The following characters are:

: for this property cable B is more suitable than cable A
: for this property cable B is less suitable than cable A
: cable B is equal to cable A

All information subject to change, technical changes reserved.
