Cable with FEP Sheath

FEP Koaxialkabel als Meterware — FEP Coaxial Cable

FEP (Fluorinated Ethylene Propylene)
Insulatoin material with exceptionally good electrical, thermal, chemical and mechanical properties. Permanent temperatures of up to 205°C and operating temperatures of up to -90°C are possible.

	Outer diameter	Impedance	Frequency max/GHz	Material	Cable attenuation 1GHz	Data sheet	Article
RG 178 (Habia)	Ø 1.75 mm	50 R	2.5	FEP	1.48 / db	18.22KB	050173
M17/93-RG178 (M) (Habia)	Ø 1.80 mm	50 R	2.5	FEP	1.48 / db	37KB	050191
RG 178 B/U (H&S)	Ø 1.80 mm	50 R	3.0	FEP	1.62 / db	229KB	050124
M17/113-RG316/C (Habia)	Ø 2.45 mm	50 R	2.5	FEP

…

D-Sub Connectors

Category: News @en, Anschlussbox, Cable assembly, Coaxial cable, Products Tags: Connection box

D-Sub Cable Whip

A cable whip is a certain type of cable adapter, consisting of a multi-pole connector, which transitions into several lines, each with a single connector. Mostly we offer these adapters in combination with our breakout boxes.

The feed of several participants is done via the connectors of the box and is led together to one connector (e.g. D-Sub), so that all signals are led via the cable whip to the corresponding end devices. This may be, for example, a measuring device.

Such an adapter can consist of 2-10 single cables, whereby the limitation mostly results …

Pre-assembled cables on drums

Category: News @en, Cable assembly, Coaxial cable, Pre-assembled cable, Accessory Tags: cable assembly @en, coaxial cable @en

For flexible use on site, we reel your ordered coaxial cables for you on a cable drum from the manufacturer Schill. Your advantage: the cable is safely stored and mobile. Whether one or several cables, we take care of all the work involved, such as bundling several cables or integrating your desired connection into the cable drum.

Variants of pre-assembled cable drums:

With a single cable or as a multi-cable
With / without rubber handle
With plug connector integrated in the cable reel housing
Cable length up to 100m

To maximize safety, we recommend having the reels fitted with cover …

As of now: Reduced conditions for universities

Category: Coaxial cable, Consulting, General, News @en, Online-shop, Purchase and price comparison Tags: cable assembly @en, coaxial cable @en

The promotion of the education sector is a special concern for arnotec GmbH. We have therefore decided to adapt our conditions for universities, colleges and similar institutions. We want to make our contribution to the next generation of researchers and scientific progress.

In addition to a payment term of 30 days net, also for new customers, we offer a special discount of 5% on our entire range of cable assemblies. The pre-assembled coaxial cables from koax24 and the stranded cables from litze24 impress with their high quality workmanship and only the best materials. Even deliveries at short notice can …

Coaxial Adapters

Category: Cable assembly, Cable configurator, Coax Cable configurator, Coaxial cable, Online-shop, Products Tags: cable, cable assembly @en, coaxial cable @en, plug, Socket

You can’t find the right type of connector for the type of cable that is essential for your application. Who hasn’t encountered this problem? You can easily overcome this challenge with our matching adapters. These help you to combine a wide variety of connector types so that you always have the right solution to hand.

Despite our high standards to provide all suitable connector types for every coaxial cable, it is unfortunately still possible that the availability of your desired connector on the market is limited. This is where our high-quality adapters from various manufacturers such as Telegärtner or

…

Difference between wire and strand

Category: Cable assembly, Cable configurator, Coaxial cable, Consulting, General

If you deal with the subject of cables, sooner or later you will come across the terms wire and strands. But what exactly is the difference or are they actually describing the same thing? This article takes a closer look at the main features of wires and strands and identifies the different areas of application.

Wires:

A wire consists of only a single conductor, often made of copper or steel, which is partly dependent on the diameter of the cable. For very thin cables, a steel wire is often used to ensure stability, which is often silver-plated …

D-Sub Kits

Category: News @en, Anschlussbox, Consulting, Online-shop, Products Tags: Breakoutbox, coaxial cable @en, Connection box

With the help of our D-Sub kits, you are guaranteed to achieve consistent high quality and spacing inside the housing, even with thin coaxial cables. They provide you with everything you need to make your own D-Sub adapter or cable whip.

Such an adapter can consist of 2-10 single cables, whereby the limitation mostly results from the diameter of the used cable type. 10 cables with a large diameter tend not to fit through the grommet of the D-Sub housing, so it would be advisable to use a thinner cable.

The circuit boards with optimized layout are …

Breakout Box BNC to D-Sub 37pol.

Category: Anschlussbox, Online-shop, Products Tags: Breakoutbox, Connection box, Signalanschlussbox

Our passive signal connection box is equipped with BNC sockets as well as a 37-pin D-Sub socket. By default, the signals are all passed on 1:1 to the pins of the D-Sub connector. Signals can also be transmitted over longer distances using a suitable connection cable. The common connection via the D-Sub connector enables the connection cable to be changed quickly without having to disconnect an individual BNC connection.

We offer our breakout box in various standard versions with 6, 8, 12 or 18 BNC sockets. The connection is made via a standard D-Sub female connector or according to customer

…
